Single board computers

ERNI WHITEspeed is a powerful, reliable and space-saving embedded computer. In developing these COM products, ERNI has been able to draw on its extensive experience in the field of board and backplane design in addition to its core competency ...

WADE-8017 is based on Intel? Q170 chipset and and desktop processor sku like Core? i7 and i5. WADE-8017 of the Intel? platform will provide high performance and flexibility for functional expansion, such as Gaming, Kiosk, DS, Medical, ...

Freescale ARM Cortex-A9 i.MX6 @ 1.2 GHz Single-, Dual-, Quad-Core 2D / 3D graphics acccelerator imaging processing unit 256 - 2048 MB DDR3 DRAM 0 - 512 MB SLC-NAND FLASH 2 / ...

Single Board Computers (SBCs) have the task to integrate the functionality of a standard motherboard on the smallest space possible and to even add features that are required in industrial applications. We mainly process SBCs in 8.89 ...

Portwell PQ7-M107 is designed with Intel? Atom? N3000 series processor. PQ7-M107 Quad core processor features low power than previous Atom platforms. PQ7-M107 could be implemented in manufactory, transportation and automation applications. ...

TI Cortex-A8 AM3505, 600 MHz (AM3517 with 3D graphics accelerator) 0/128/256 MB NAND FLASH (available up to 1024 MB) 128/256/512 MB DDR2-333 Onboard microSD socket ...

The IB908 is a compact SBC supports 4th Generation Intel? Core? processor family U-series with BGA1168 (MCP) socket that offers significantly lower power design compared to previous generations. The IB908 is the ideal platform for demanding ...

Intel Core 2 Duo Featuring a 64-Bit Dual-Core 1.5 GHz Processor Mid-Size, Single Compute Module High-Performance Computing Solution for AdvancedTCA and MicroTCA Systems MiniSD Site for Onboard Program ...

COM EXPRESS? BASIC TYPE 6 WITH 5TH GENERATION INTEL? CORE? PROCESSORS SPECIFICATIONS Intel? 5th Generation Core? i7 with QM87 With non-ECC DDR3L up to 16 GByte Triple independent display support with 4k resolutions

The IB897 3.5-inch disk-size single board computer is based on the latest generation of Intel? Atom? processors. The IB897 integrates the 22nm quad-core Intel? Atom? E3845 processor that features 1.91GHz clock speed, 10-Watt power consumption, ...

3.5" SBC with Intel? ? i3/i5/i7 processor VGA, COM, 2 x DP, 2 x USB3.0, 2 x SATA, HD Audio, 1 x LAN

Freescale Dual-Core 1 GHz MPC8641D PowerPC Processor Mid-Size, Single Compute Module High-Performance Computing Solution for MicroTCA Based Application-Ready Systems PCI-Express and Serial RapidIO Options ...

The brandnew application-ready COMe-bHL6 offers increased performance density and up to twice the graphics performance compared to its predecessors. Up to three independent, daisy-chained displays with up to 4K resolution are supported ...

Uses Rabbit? 4000 and Rabbit 5000 microprocessors Choice of Wi-Fi, ZigBee or Ethernet connectivity 40 digital I/O and up to 5 serial ports 8 input and 2 output analog channels Advanced I/O subsystem is software configurable reducing the ...

Intel Atom E38xx-based SBC with StackPC Expansion Connector in 3.5? Form-Factor CPB909 ? CPU Intel Atom E38xx ( 1.33-1.91 GHz) ? DDR3L-1066/1333 SDRAM up to 4 GB with ECC support ? Integrated graphics controller, 2D/3D ? accelerator ? ...

Single Board Computer - AM3352 Prozessor (ARM Cortex? - A8 Core) by Texas Instruments Key functionalities: Suitable for industrial use Long term availability Low power consumption 2x IEEE1588 Ethernet (internal switch) Sound and graphics ...

Kontron?s Computer-on-Module for COM Express? basic with 3rd Generation of Intel? Core i-Series. With support for Pin-out Type 2 and Type 6, Kontron?s module covers both the need for latest interface technology and the need to extend ...

CPU: Intel Atom: E3845: 1.91 GHz, 4x core, (CPC1311-01 version); E3825: 1.33 GHz, 2x cores, (CPC1311-02 version) E3827: 1.75 GHz, 2x cores, (CPC1311-03 version) ? L1-Cache (32 KB of instructions, 24 KB of data); L2-Cache 1024 KB ? ...

The Apalis T30 is a small form-factor Computer on Module based on the NVIDIA? Tegra 3 SoC. The Cortex A9 quad core CPU offers an operational frequency up to 1.4 GHz. The module offers high performance and advanced graphic capabilities ...

In 2011, Intel? introduced its first quad core CPU suitable for the COM Express? platform. With the quad-core CPU Core? i7-2715QE and the dual-core CPUs Core? i3/i5/i7, COM Express? reaches ground-breaking performance values: both for ...

3.5" ECX on-board Intel? Atom? D525 1.8GHz CPU Main Feature Support Intel? Atom? Dual Core D525 Processor Support DDR3 SO-DIMM SDRAM, up to 2GB Support VGA/ LVDS 18/ 24-bit Display Dual Intel Gigabit Ethernet ...

The CB30C CPU is a safe Rugged COM Express module based on NXP/Freescale QorIQ for safety-related applications meeting EN 50129 SIL 2, for rolling-stock or industrial control systems.

Kontron is extending the usage model of the 5th generation Intel? Core? processor technology to compact and rugged fanless options with the launch of the Kontron COMe-cBL6 COM Express? compact Computer-on-Modules. The new modules in the ...

3.5" ECX On-board Intel? Atom? Processor E3800 Product Family HDMI/VGA/1 x24/48-bit LVDS Dual Channel, Dual Mini-PCIe Main Feature On-board Intel? Atom? Processor E3800 Product Family One 204-pin SO-DIMM socket supports up ...

The CC10S is a small-footprint multi-display controller for 7" to 15" panels based on the NXP (formerly Freescale) ARM i.MX 6 Series, for driver desk displays or in-seat infotainment in trains or public buses, in medical devices, or automotive HMIs.

i.MX6 Pico ITX SBC is the Industry?s latest Single Board Computer around Freescale i.MX6 that includes Quad, Dual, DualLite and Solo core families based on the ARM? Cortex?-A9 architecture which is iWave?s 4th i.MX6 based designs. Measuring ...

The Intel LGA1155 Sandy Bridge Full-size SBC has a PICMG 1.3 System Host Board (SHB Express) and 2 x DDR3 Long-DIMM Sockets up to 8GB. It supports LGA1155 Sandy Bridge Processors and RAID 0, 1, 5, 10. It also supports Intel Rapid Storage ...

Intel? Pentium?/Celeron? SoC Processor 3.5? Micro Module Onboard Intel? Pentium?/Celeron? SoC BGA ProcessorOne 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1600 SDRAMDual Display (HDMI, LVDS)1 SATA III, 4 USB 3.0, 2 USB 2.0 ,5 ...

The ConnectCore 6 is an ultra-compact and highly integrated system-on-module solution based on the NXP/Freescale i.MX6 Cortex-A9 processor family. With processor speeds up to 1.2 GHz and fully pin-compatible single-/dual-/quad-core ...

iW-RainboW-G16S, Vybrid Pico ITX Single Board Computer based on Freescale?s Vybrid VF6xx/VF5xx family solution combining ARM Cortex-A5 and Cortex-M4 cores often eliminates the need for an external MCU for real time control applications. ...

The MPC7447A or MPC7448 is a processor that can work for SBC or OS integration setup. The MPC7447A 1GHz microprocessor uses 512kb of L2 cache and 32kb data with parity. The MPC7448 1.4GHz processor is made with 64mb of mirror flash, 256mb ...

6th Gen Intel?Core ? Processor i7/i5/i3 3.5?Micro Module with Intel? QM170 Chipset Onboard 6th Gen Intel?Core ? i7/i5/i3 BGA ProcessorOne 260-pin DDR4 SODIMM Socket, Supports Up to 16GB DDR4 2133 SDRAM (only support non-ECC)Dual-channel ...

The ConnectCore 6 SBC is an ultra-compact and versatile off-the-shelf single board computer (SBC) platform. It offers significantly reduced time-to-market by virtually eliminating the traditional risk, effort, and complexity of custom ...

Tested with many COM Express modules from different CPU module vendors. Suitable for "rapid prototyping" and also for massproduction in low, middle and high volumes. External Interfaces: 2x Gigabit Ethernet, 4x USB, DVI-I, ...

An SBC can be powered with a new package in the Intel Core i5 and i7 setup. The device is built to work with the mezzanine and OS options with just one assembly number. It comes with a 3U VPX N-Series board computer that is equipped with ...

The PICO-IMX6-SD reference design based on the NXP i.MX6 multimedia processor is a purpose-built, small footprint hardware platform equipped with a wide array of high-speed connectivity engineered to support IoT endpoints, wearable applications, ...

DM&P SoC CPU Vortex86DX2- 800MHz 512MB/1GB DDR2 onboard Watchdog Timer, software programmable from 30.5 ?sec. to 512 sec. Integrated 2D VGA chip, share system memory 16MB/32MB Integrated ALC 262 HD Audio Integrated 10/100Mbps Ethernet Onboard ...

Based on the ARM? Cortex ?-A8 core, TI AM3703 / AM3715 and DM3725 / DM3730 1GHz Low Power Application Processor O.S.: Linux 2.6 or Windows? CE 6.0

Ruggedize your SBC or pack it within a entirely included bundle which include mezzanine possibilities and Operating system incorporation supported and sold beneath a one construction quantity. Capabilities: second era Intel? Core? ...

DM&P SoC CPU Vortex86DX- 800MHz 16-bit x-ISA interface 256/512MB DDR2 onboard Watchdog Timer, software programmable from 30.5 ?sec. to 512 sec. XGI Volari Z9s Chipset, onboard 32MB VGA Memory Audio out Integrated 10/100Mbps Ethernet Onboard ...

An SBC can become stronger with a mezzanine option and OS integration support for one assembly number. The TIC-PQ3-VPX3a works for many OpenVPX profiles in the VITA 65 setup including the SLT3 series of units.

3rd Gen. Intel? Core? i7/i5/i3 / Celeron? processors with Intel? Q77 chipset Two 240-pin DIMM up to 16GB DDR3 1333/1600MHz SDRAM Dual Display: VGA/DVI-D Two Intel? Gigabit Ethernet ports 4 PCI, 1 PCIe x4, 1 PCIe x16 and 1 Mini-PCIe (w/ ...

Bay Trail-I E3825 1.33GHz (Dual core processor) MB Chipset Intel Bay Trail-I E3825 chipset BIOS Insyde UEFI BIOS Graphics Intel's 7th generation (Gen 7) graphics and media encode / decode engine, Supports DX*11, OpenGL 3.0 (OGL 3.0), ...

Build around the second generation of PowerQUICC III designed by Freescale Semiconductor using 90 nm technologies, the new CSBX-3545A set a new level of performance per watt with power dissipation at 1.2 GHz similar to the previous generation ...

This 3U VPX Single Board Computer is a TIC-PPC-VPX3a model. It features a 1GHz single/dual Core Freescale MPC8640 processor and can support up to 2GB of DDR2 SDRAM memory with ECC. It also features one RS232/422/485 interface and dual ...

Intel? Atom? D525 based PICMG 1.0 SBC with VGA/DVI-D/ LVDS, 3 SATA II, 6 COM, 8 USB, Dual GbE LAN.Intel? Atom? D525 processor with Intel? ICH8M chipset Two 204-pin SO-DIMM up to 4GB DDR3 667/800MHz SDRAM Dual Display: VGA/DVI-D/LVDS Two ...

Embedded Intel? Bay Trail-IE3825 CPU / chipset ? On Board 2G DDR3L, VGA, eDP, Touch Screen, Audio ? 1 x Intel GbE LAN, 1 x USB 3.0, 2 x USB 2.0, COM ? 1 x Mini PCIe for PCIe / USB / mSATA. M.2 B Key

This computer board is based on the MPC8270 from MOTOROLA (PowerQUICC II). This processor is rated up to 855 MIPS @ 450 MHz and includes a very efficient SDRAM controller. One of the key feature of this device is to include a Quad Integrated ...

AMD R-Series APU Bald Eagle + A77E Dual DDR3L-1600 SODIMM sockets up to 16 GB Four Independent Displays with outstanding graphics performance Plenty high speed interface, PCIe x16 Gen3, SATA Gen3, USB3.0 Supports ...

The LANNER VES-310 offers the advantage of solid processing power while reducing power consumption. The unit is equipped with 1.66GHz Atom and offers many features like memory support up to 2GB DDR2, dual GbE LAN ports, compactFlash ...

Intel Diamondville 1.6GHz N270 single core Atom Processor Intel 945GSE Northbridge (NB) and ICH7M Southbridge (SB) chipsets Single DDR-2 SO-DIMM supports up to 2GB 400/533MHz memory Intel GMA950 graphic engine integrated ...

The SCS750? single board computer for space is Maxwell's answer to the space industry's need for medium- to high-performance computing. The SCS750 combines the latest generation of IBM PowerPC? processor with large amounts of volatile ...

Embedded Intel? Core? i7/i5/i3/Celeron? ULT processor + Lynx Point LP Supports Dual Channel DDR3L-1333/1600 SODIMM sockets up to 16 GB Supports 4 PCIex1, 1PCIex1, 8 USB 1.1/2.0, 2 USB3.0, 4 SATA Supports 3 independent ...

Intel Cedar Trail 1.86GHz N2800 dual core Atom Processor Intel NM10 Express chipset Supports Smart Battery for portable applications Single DDR-3 SO-DIMM supports up to 4GB 800/1066MHz memory Intel Embedded Graphic ...

FEATURES > Support Intel? Atom? N455 1.66GHz / D525 1.8GHz processor > Memory support DDR3 SO-DIMM 800 MHz SDRAM up to 2GB > Support two 10/100/1000 Mbps Ethernet > Fanless solution (N455) > Compact flash

Embedded Intel Atom/Celeron Processor E3845/N2920 Dual DDR3L-1333/1066 SODIMM sockets up to 8 GB Supports VGA, LVDS, HDMI/DVI/DisplayPort Support 3 PCIe x1, 8 USB2.0, USB3.0, 2 SATAII, LPC, SMBus, I2C Supports iManager, ...

FEATURES Onboard Intel? Core? i7-610E / i3-330E Processor, up to 2.53GHz Two DDR3 DIMM, Max. 8GB memory, supports ECC Supports CRT, DVI-D, HDMI, LVDS and Display port Intel? 82577LM Gigabit PHY 4x SATA II (RAID ...

The Ensemble? 6000 Series OpenVPX (VITA 65) HCD6220 Module is designed as a VITA 46 VPX-compliant module in a 6U form factor, also compatible with OpenVPX? system architecture design principles. This module combines high-performance Power ...

AMD G-Series Single Core T16R processor + A55E, DDR3 SODIMM up to 4GB DirectX11 supported. 48-bit LVDS, VGA, 18-bit TTL Dual GbE, 4 COM, 2 SATA, mSATA Expansion: PC/104, Mini PCIe, LPC connector for additional COM ports ...

Supports Intel? Core?2 Duo processors, up to 2.4GHz, 533/667/800MHz FSB 2x DDR2 DIMM, Max. 4GB Intel? GMA X3100 VGA for CRT/LVDS, Chrontel 7307C for DVI support Integrated Gigabit LAN, optional Marvell PCI-E Gigabit ...
