PXI Express controller card / serial

The MXIe PXI-Express Bus Expanders allows for direct control of PXI-Express systems from any PCI Express slot in a desktop computer or server. MXIe-Express configurations are available for supporting both the x1 and x4 PCI-Express lane configurations. Either lane configuration can remotely control one or two PXIExpress chassis. The MXIe-Express technology utilizes a high bandwidth link that is transparent to software applications and drivers, providing the ability to use high performance desktop computers or servers to control PXI-Express systems.

Features
Since PXI-Express is based on the industry-standard PCI-Express bus, the MXIe-Express Bus Expanders provide a transparent link where all PXI and PXI-Express modules appear to the user as if they were PCI or PCI-Express boards within the computer itself. However, with PXI technology, users benefit from an increased number of slots, power and cooling per slot, module selection, and synchronization features. The MXIe-Express employs a high speed serial link to control the PXI-Express chassis. Interfacing cables for the MXIe-Express are available in 1, 3 and 7 meter lengths for the x1 interface and 3 and 7 meter lengths for the x4 interface.
